| Specifications | |
| Item | MAVPQ 32L |
| Panel Size | Min:250*250mm/Max:960*760mm |
| Stencil Size | Min:900*900mm/Max:1100*1100mm |
| Panel Thickness | 0.1-12mm |
| Applicable Through Hole Size（After plating） | ≥0.08mm |
| Applicable Min Blind Hole Size（After plating） | ≥0.05mm |
| Printing Table Height (with foot step) | 1150±50mm |
| Limit Vacuum | 5Pa |
| Efficiency | 20-100pnls/h |
| Aspect Ratio（After plating） | Through hole<80：1，Blind hole<8：1 |
Features
Easy operate
Limit vacuum degree is 5Pa
No void and crack in hole
Lighter unit weight for any floor≤700kg/m²
High utility of ink
High repeatability of printing table
Selective plugging
CCD alignment, within 5 minutes to make the 1st panel
